Automatic Liner Bottle Washing Machine

Automatic Liner Bottle Washing Machine
Automatic Liner Bottle Washing Machine
Product Code : A2
Brand Name : Parth
Product Description

Description:

High-speed Linear Bottle Washing Machine is perfect for Round Bottles, and finds broad uses in Food & Beverages and Pharma Industries. Automatic loading arrangement installations for loading of bottles onto the S.S. wire mesh conveyor with the help of feed conveyor / bottles, are forced manually from feed table. This process saves on manpower, as the bottles are feed automatically into pockets. The mechanism of automatic unloading consists unloading bottles, proceed on to the Turn Table (Optional).

Technical Specification:

Model

PLBW-150

Output / Hour*

Up to 9000 Bottle

No. of Pocket Across

10

Power**

Consumption

Main Motor

1 HP / 415 Volts / 50 Hz

Pump Two Nos.

0.5 HP / 415 Volts / 50 Hz x 2 Nos

Electrical Heater

3 Kw.

Wash Cycle

4 Inner + 1 Outer + 1 Air

Machine Dimension



Case Dimensions



Net Weight



Gross Weight



Input Specifications:

Round Shape

(A) 30 mm to  65 mm***

(B) 58 mm to 190 mm*** (Height option for other bottle height available)

(C) 20 to 55 Neck Diameter***

Flat / Square

(A) 30 mm to 100 mm (Length)***

(B) 10 mm to 50 mm (Width)***

(C) 58 mm x 190 mm (Height option for other bottle height available)

* Depends on bottle size.

** We can supply as per customer requirements.

*** With help of change parts.

Salient Features:

  • High-pressure pump ensure proper wash of bottle.
  • Contact parts S.S. 316 Non Contact parts S.S. 304 Including the basic frame.
  • Suitable for Round and Flat Glass Bottle (with help of change parts).
  • Water re-cycling provided as per customers SOP.
  • For high volume container wash provided high pressure centrifugal pump (Optional).

Utility Requirement:

Electrical supply

3 Phase + Neutral + Earthing

Air Consumptions

2.5 Kg Air Pressure / 20 CFM
